A hybrid rigid-flex design is an ideal solution for combining standard PCB construction with flexible materials, such as copper traces, to achieve the necessary mechanical stress tolerance. The resulting PCB can safely bend while still providing reliable electrical connections. However, there are a number of factors that must be considered to prevent mechanical failure and ensure quality.

Rigid-flex boards can be used in a variety of applications, from handheld devices to medical equipment and automotive systems. In addition, they can withstand high temperatures and absorb vibration in high-stress areas, making them ideal for use in challenging environments. They also offer a lower cost than standard rigid PCBs, and can be produced in short lead times.

PCB fabrication for hybrid flex pcb fabrication involves the same processes as rigid pcbs, with additional steps to support the flexibility of the flex area. Specifically, a stiffener or rigid area is added around the flex section of the board to keep it from bending too much and to protect components or connectors attached there. A stiffener is typically made from FR-4 or Kapton material. The thickness of the stiffener is important because it can impact the stiffness of the finished flex circuit.

Can flex PCB fabrication support hybrid rigid-flex designs?

The layers of a flex circuit are printed and etched, with copper traces acting as the electrical pathways between the rigid and flex sections. During this process, it’s critical to consider the electrical, mechanical, and thermal performance of each layer, as well as the overall board thickness. Additionally, it’s vital to account for the size and shape of the rigid-flex region. For example, S curves are recommended over straight segments to reduce the likelihood of cracking due to mechanical stress.

Hole patterns for pads and vias on a flex circuit are usually mechanically drilled using a precision drilling system or laser drill. For the best results, it’s essential to choose a manufacturer that is familiar with rigid-flex PCB design rules and manufacturing techniques. For instance, a manufacturer should be able to drill small holes (less than 1 mil) using Excimer lasers for the highest accuracy and lowest outgassing, and CO2 lasers for medium holes (4+ mils).

Once the flex circuit is complete, it’s joined to the rigid section of the board through the copper plating process. A final through-hole is plated in the rigid section to complete the circuit’s assembly. Once the plated copper is dry, a solder mask is applied to the entire surface of the rigid-flex circuit to protect it from corrosion and oxidation.

A rigid-flex circuit can be used on its own or bonded to an external frame or structure using pressure sensitive adhesive. For the latter, it’s critical to use a material that is compatible with the application and will adhere well in an environment with high temperatures and moisture. Choosing the right material will also help avoid thermal and mechanical stress, which can affect the integrity of the bond. For example, a heat-resistant material such as polyimide is recommended.
