Dissipation in Flex Circuit PCBs

Compared to rigid printed circuit boards (PCBs), flex circuit PCBs are much more flexible and offer many different layout options. However, they are also more prone to temperature variations and need special considerations to ensure they are able to withstand high temperatures and other stressors. To maximize your flex PCB’s durability and longevity, it is important to understand how you can handle heat dissipation in the material and assembly process.

The most common material for a flex circuit is polyimide. This is a very flexible material that can be bent, twisted and stretched without compromising its electrical conductivity. It is highly tolerant of product assembly and soldering processes and can be used in a variety of applications. It is commonly paired with another material, such as a glass fiber or epoxy-and-glass-fiber core, and an additional PI or PET film for coverlay. This helps to protect the copper traces from damage, similar to how solder mask ink does on rigid PCBs.

In addition to the materials and fabrication techniques, there are also some specific components that can be used in a flex circuit to help with its heat dissipation. For example, using heat sinks on critical areas of the flex circuit pcb can improve its ability to dissipate heat. This is because the sinks act as a heat-exchange element that transfers thermal energy from the flex circuit to the surrounding environment.

Other methods for improving heat dissipation in a flex circuit include incorporating air flow channels or fans to cool the circuit, and incorporating thermal vias. These are plated through-holes that provide an additional path for heat transfer and can be useful in reducing hot spots in the circuit. Additionally, ensuring that the flex circuit is properly positioned and that its components are placed close together can also optimize heat dissipation.

Heat Dissipation in Flex Circuit PCBs

The maximum temperature that a flex circuit can withstand is influenced by the application and operating conditions, as well as the manufacturing processes. It is important to follow the recommended temperature profiles and guidelines provided by your flex circuit manufacturer.

When creating a flex circuit, it is important to choose the right copper thickness, width and spacing. For instance, if the circuit will be subject to repeated bending and movement, you should use higher-grade rolled annealed (RA) copper. This is more flexible and less prone to work-hardening than unannealed copper, which can cause fatigue cracking. RA copper is also springier in the Z direction, making it ideal for flex circuits that require repeated bending or movements.

Using curved rather than straight traces is another way to reduce stress on a flex circuit’s copper surfaces. This reduces the chance of stress-induced breaks, as well as minimizing current leakage in tight spaces. The copper traces should be evenly spaced and have a smooth transition between thin and wide sections, as this can also prevent the formation of stress concentration spots.

When connecting traces or plated through-holes on a flex circuit, it is best to use teardrop (pad fillet) shaped vias. This minimizes the potential for stress concentration spots and provides a stronger connection between the pad and the copper trace.
